June 09, 2019

TL;DR: Just press s to slow-mo…

cheng lou "Cheng Lou - The State of Animation in React at react-europe 2015"

It’s Sunday, June 9th, 2019. 2 engineering sprints down, 4 work weeks passed, 160 hours of work-programming logged. It’s alot and it’s great. I learn so much new stuff that it’s nearly impossible to stick to one topic when I try to write these blog posts. Also, I don’t think I even like writing, but I’m adhering to my brother’s initial suggestion to blog about my learning process.

I initially wanted to write about react-spring, but I realized that I should probably recap on my belated undestanding of redux.


My REDUX understanding:

one store

You have one, and only one store that holds your application’s state.

reducers listen for actions

That store has reducers, which are functions that listen for actions, and “do something” based on the action, such as updating the global state.

dispatch actions to store; update store

You need to dispatch actions to the store, from your components. How?

‘react-redux’ for connecting components

The react-redux library has a connect() higher order function that connects your components to the store, in 2 major ways:

  1. It allows you to create dispatch handlers, available as props. These handlers have access to the store’s dispatch() method.
  2. The connect() function also allows your components to read from the store, and map the state to their own props.

That’s pretty much the circle-of-life for redux. Then there’s also more cool stuff with redux-persist for persistent local storage. I also need to learn about the thunk middleware for asynchronous stuff. I need to nail down asynchronous programming in general actually.


Onto the slow-mo thing

Though I don’t get to use react-spring for work, I try to squeeze in time on weekends, or even between weekdays to learn it, as well as other cool libraries. So I remember this video by Cheng Lou, which I watched during my previous internship. When he hit the audience with the slow-mo, my mind exploded. But ever since, I never tried to figure out how he managed to do that, nor thought that I would ever have a use case where I needed to do that… until last night.

Last night, I decided to refactor some of my blog. I decided to try to figure out react-spring’s useTrail(), which lead me to adding a trail of cute logo SVGs, from my other website.

Random code chunks/notes

Later SVGs move slower

// SVG animation trail configs
const zero = { mass: 2, tension: 500, friction: 30 }
const one = { mass: 3, tension: 400, friction: 32 }
const two = { mass: 4, tension: 300, friction: 34 }
const three = { mass: 5, tension: 200, friction: 36 }
const four = { mass: 6, tension: 100, friction: 38 }

const configs = [zero, one, two, three, four]

useTrail() declaration

/**
 * useTrail() 👉 https://www.react-spring.io/docs/hooks/use-trail
 * @param {number} count The number of animated "things"
 * @param {func} getProps
 *
 * @return {array} [trail, set, stop?]
 *
 * @usage trail.map(props => <animated.div style={props} />)
 */
const [trail, setTrail] = useTrail(5, () => ({
  xy: [0, 0],
  // (property) config?: SpringConfig | ((key: string) => SpringConfig)
  config: i => configs[i],
}))

Styling my SVGs

/**
 * An array of SVGs to be rendered by `trail.map((e,i) => {})`
 */
const SVGS = [SVG.REACT, SVG.APOLLO, SVG.PRISMA, SVG.GRAPHQL, SVG.NODE]

const StyledSVG = styled.div`
  background: rgba(255, 255, 255, 0.5);
  border: 1px dotted white;
  border-radius: 100%;
  box-shadow: 0px 3px 5px -1px rgba(0, 0, 0, 0.2), 0px 6px 10px 0px rgba(0, 0, 0, 0.14),
    0px 1px 18px 0px rgba(0, 0, 0, 0.12);
  display: flex;
  padding: ${props => props.index && props.index * 5 + "px"};
  pointer-events: none;
  position: absolute;
`
const AnimatedSVG = animated(StyledSVG)

an “interpolate” handler

// you can add _.random() in here for some weird behavior. (no rerenders!)
const translate2d = (x, y) =>
  `translate3d(${x}px,${y}px,0) translate3d(-50%,-50%,0)`

the slowMo state hook…

const [slowMo, setSlowMo] = useState(false)

Implementation

return (
  <div
    onMouseMove={e =>
      setTrail({ xy: [e.pageX, e.pageY], config: slowMo && config.molasses })
    }
    onKeyPress={e => {
      console.log(e.key)
      e.key === 's' && setSlowMo(state => !state)
    }}
  >
    {trail.map((props, index) => (
      <AnimatedSVG
        key={index}
        index={index + 1}
        style={{
          transform: props.xy.interpolate(translate2d),
        }}
      >
        {SVGS[index]}
      </AnimatedSVG>
    ))}
// etc.

Neo

What are you trying to tell me? That I can dodge bullets?

Morpheus

No, Neo. I’m trying to tell you that when you’re ready, you won’t have to.

Me

Going to make some pancakes. Bye 👋
